The self balancing axial force multi-stage high-pressure boiler feed pump with cooling device is a combination of advanced technology from similar foreign products to meet user needs and accelerate the development of high-pressure multi-stage pump technology.A high-efficiency high-pressure multi-stage centrifugal pump product developed according to the APII610 standard.
It has the advantages of high efficiency and energy conservation,wide performance range,good cavitation performance,safe and stable operation,low noise,few vulnerable parts,and convenient installation and maintenance.
The DGP type self balancing boiler feed pump(with cooling device)has innovated in the structural form of the traditional multi-stage segmented centrifugal pump,eliminating the axial force balance mechanism of the old multi-stage centrifugal pump and adopting a balance plate or balance drum structure.
The self balancing multi-stage pump has no balancing device,which means that there is no friction loss of the circular disc without a balancing disc and no balancing return flow loss.Therefore,the pump efficiency is much higher than that of similar old multi-stage pumps,while solving various faults such as wear or rotor seizure caused by the failure of the balancing device on the balancing disc and its seat,
Greatly extend the service life of the pump.
The trouble-free running time is multiple times that of a regular pump,greatly reducing the maintenance cost for users,thereby reducing the lifespan and maintenance cost of the pump.Years of operation have proven
that the performance of this product has reached the advanced level of similar international products.
DGP type self balancing boiler feed pump(with cooling device)is used to transport solid particles of no more than 2%dry(particle size less than 1m),and the solid concentration of the medium is less than 5%Wt.Liquid used for water with a temperature≤105℃or other liquids with physical and chemical properties similar to water.
It can also be used to transport hot water,oil,corrosive or abrasive media with a temperature≤210℃by changing the material of the pump(or the material of the pump's flow components),sealing form,and adding a cooling system.
The pump materials include HT200,OT600,304,304L.316L,317L,904L,CD4,etc.for users to choose from.
Self balancing axial force multi-stage high-pressure boiler feed pump with cooling device Main purpose:
●Boiler water supply system and condensate transportation in industrial equipment
●Medium transportation in petrochemical,coal chemical,and chemical industries
●Cold water delivery in shear equipment
●Pressure water delivery in oxidation removal equipment
●High pressure water production in industrial processes
●Chemical process flow
Oilfield water injection and mine drainage
●Brine extraction and transportation
●Water transportation for compressors,shellers,and other equipment
